Titanium Pedal Spindle is a lightweight clipless pedal replacement component engineered for Clipless pedal replacement spindle axle. Forged and CNC machined from Grade 5 Ti-6Al-4V, it achieves 40-45% weight savings versus steel while maintaining the fatigue life required for demanding cycling applications. Threaded interfaces are designed to prevent galling in outdoor environments.
Titanium Pedal Spindle
| Technical Parameter | Specification |
|---|---|
| Component SKU | TI-CYC-PEDA-TITANI |
| Standards & Specifications | MIL-STD-810HASTM B117 |
| Surface Finish | PVD TiAlN coating (2-3um, HV2500) |
Titanium Pedal Spindle
Clipless pedal replacement spindle axle
| Technical Parameter | Specification Value |
|---|---|
| International Compliance | MIL-STD-810H, ASTM B117 |
| Surface Finish & Max Temp | PVD TiAlN coating (2-3um, HV2500) |
| NDT & Quality Control | Ultrasonic Testing (UT) per ASTM A388; Liquid Penetrant Inspection (LPI) per ASTM E1417; Dimensional verification via CMM |
- • 100% Traceability: Mill Test Certificate (EN 10204 3.1) with heat analysis & mechanical testing.
- • NDT Verification: Ultrasonic Testing (UT) per ASTM A388; Liquid Penetrant Inspection (LPI) per ASTM E1417; Dimensional verification via CMM.
- • Compliance: REACH, RoHS 3 certified. FAI AS9102 available.
- • Process: 5-axis CNC contouring, electropolishing, ultrasonic clean, vision inspection.
- • Thermal Stress Relief: Post-machining vacuum annealing (540-675°C under Argon) reduces distortion risk >70%.
- • Rolled Threads: Thread rolling (not cutting) increases fatigue limits by 30-50%.
Q: How much weight savings does Titanium Pedal Spindle offer versus steel or aluminum? ▼
Titanium Pedal Spindle fabricated from Grade 5 Ti-6Al-4V provides a 40-45% weight reduction versus 4130 chromoly steel (4.43 vs 7.85 g/cm³) at the same strength. Compared to 6061-T6 aluminum, titanium's 3× higher yield strength (830 vs 275 MPa) allows 50-60% thinner walls, resulting in a net weight comparable to aluminum with 4× better fatigue life — critical for clipless pedal replacement.
Q: What is the typical lead time for Titanium Pedal Spindle orders? ▼
Standard lead time for Titanium Pedal Spindle is 15-25 business days depending on quantity and complexity. Rush orders (3-5 working days) are available for prototype evaluation. Sample evaluation (1-5 units) can be expedited to 5-7 business days. Volume pricing is available for production quantities above 100 units.
Q: What material certifications are provided with Titanium Pedal Spindle? ▼
Each Titanium Pedal Spindle shipment includes EN 10204 Type 3.1 mill test certificate with chemical analysis, mechanical properties, and heat identification. Dimensional inspection reports and Certificate of Conformance (CoC) are standard. First Article Inspection Reports (FAIR) per AS9102 are available on request for clipless pedal replacement.
§ Why Grade 5 Ti-6Al-4V for clipless pedal replacement
Function
A precision Pedal Hardware component designed for . The selection of Grade 5 Ti-6Al-4V provides the optimal balance of strength-to-weight and environmental resistance required for this Cycling / Bicycle application.
Specifications
- SKU: TI-CYC-PEDA-TITANI
- Category: Pedal Hardware
- Industry: Cycling / Bicycle
- Material: Grade 5 Ti-6Al-4V
- Process: 5-axis CNC contouring, electropolishing, ultrasonic clean, vision inspection
- Weight: Weight optimized through topology analysis - 30% lighter than baseline
§ Fatigue & Dimensional Inspection Protocol
Quality Management
Production executed in AS9100D-certified facility. Material certificates, dimensional reports, and surface finish certifications accompany every shipment of Titanium Pedal Spindle components.
Inspection & NDT
Full dimensional layout per AS9102 FAIR requirements; ultrasonic immersion scanning for volumetric integrity; micro-hardness traverse on heat-affected zones
§ Lightweight Component Manufacturing Process
Titanium Pedal Spindle is manufactured using 5-axis cnc contouring, electropolishing, ultrasonic clean, vision inspection. Each operation is performed by certified machinists with real-time process monitoring and dimensional verification at critical stages. Heat code traceability is maintained throughout all production steps.
