Rapid Prototyping Services
Quick turn-around functional titanium prototypes delivered in 3-5 business days — with full structural mechanical strength for physical fit checks, form verification, and functional validation.
Read more Show less
Rapid Prototyping Value Pillars
Three core advantages that make additive rapid prototyping the fastest path from design validation to production-ready titanium components.
Accelerated Time-to-Market
3-5 Business Days Lead TimeSlicing lead times down to 3-5 business days by eliminating traditional tooling setups, mold fabrication, and lengthy CAM programming — enabling rapid design-build-test loops for NPI programs.
- No hard tooling — designs go directly from CAD to printer in hours
- Parallel build scheduling for multi-part prototyping kits
- Expedited shipping via DHL/FedEx worldwide upon completion
- Same-day production start for urgent engineering validation runs
100% Functional Testing Ready
≥99.5% Relative Density, Forging-Grade StrengthFull-density titanium components with mechanical integrity equivalent to wrought forgings — built for physical destructive stress tests, proof-of-concept validation, and pre-production certification trials.
- Relative material density ≥99.5% per ASTM B311 Archimedes method
- Tensile strength 950-1,050 MPa matching forged Ti-6Al-4V specs
- Suitable for hydrostatic pressure, burst, and fatigue testing
- Material certs provided with every prototype shipment
Zero-Cost Design Alterations
Modify CAD Files, No Wasted ToolingUnlike machining or injection molding, additive prototyping allows unlimited design iterations at zero hard tooling cost — ideal for fluid engineering cycles where geometry evolves rapidly between reviews.
- Modify CAD files and re-print — no mold re-cut or fixture re-build costs
- Iterate topology, wall thickness, and internal channels freely
- Print multiple design variants in a single build for side-by-side comparison
- Digital inventory eliminates warehouse storage between iterations
Rapid Prototyping Performance Dashboard
Speed, volume, and geometric boundaries of our titanium rapid prototyping service — from single-unit NPI parts to complex lattice structures.
Standard Turn-Around Time
Shipped worldwide via DHL/FedEx — from file acceptance to delivered prototype, including printing, stress relief, support removal, and surface finishing.
Minimum Order Quantity
No minimum batch constraints — tailored for strict NPI (New Product Introduction) validation, single-unit functional testing, and design proof-of-concept builds.
General Dimensional Tolerances
As-printed parameters controlled within ±0.1 mm to ±0.2 mm bounds — suitable for fit-check and form-validation prototypes before production commit.
Lattice Strut Micro-Diameter
Ultra-lightweight structural configurations achievable with minimum lattice strut diameters down to 200 µm — enabling weight-optimized aerospace and medical lattice structures.
Hybrid Additive-Subtractive Post-Processing
Combining the geometric freedom of SLM with the precision of 5-axis machining and surface finishing — delivering prototypes that meet production-grade tolerances and surface quality.
CNC Post-Machining Integration
As-printed SLM titanium components have surface roughness (Ra 6-12 µm) and dimensional tolerances (±0.1-0.2 mm) that are insufficient for bearing bores, threaded holes, precision mating surfaces, and tight-tolerance interface features required in aerospace and medical assemblies.
Strategic Allowances on Printed Blanks → 5-Axis CNC Finishing to ±0.005 mm
- Printed blanks designed with 0.3-0.5 mm stock allowance on all critical features — bearing bores, threaded holes, dowel pin locations, and sealing surfaces
- Blanks transferred to 5-axis machining centers with integrated soft-jaw or custom fixture referencing the as-printed datum surfaces established during build
- CNC finishing achieves tolerances up to ±0.005 mm on critical features — matching full-production machined component specifications
- Single setup on 5-axis machine enables concentricity correction: printed bore centerlines are re-machined true to each other, eliminating any as-built positional drift
Surface Quality Upgrades
Raw as-printed titanium surfaces exhibit a characteristic matte texture with partially sintered powder particles, layer line ridges (Ra 6-12 µm), and occasional spatter adhesion — unsuitable for applications requiring smooth sealing surfaces, aesthetic appearance, or enhanced corrosion/wear resistance.
Bead Blasting, Chemical Polishing & Anodization — Down to Ra 0.8 µm
- Bead blasting with fine alumina or glass beads (50-100 µm) at controlled pressure removes partially sintered surface particles and reduces roughness to Ra 3-5 µm — standard finish for most prototype applications
- Chemical polishing (immersion in HF/HNO₃ acid bath) selectively dissolves surface asperities, achieving Ra 0.8 µm finish while removing an additional 10-20 µm of the as-printed surface layer — eliminating layer line visibility
- Type II anodization (per AMS 2488) builds a 2-5 µm dense oxide layer, enhancing surface hardness to 350-400 HV and providing wear-resistant passivation against galling and fretting in threaded assemblies
- All surface treatments are performed in-house with full process control — bead blast pressure, chemical bath temperature, anodization voltage, and seal parameters logged per part serial number
Tight Timeline Deadline?
Submit Your Blueprint for Accelerated Assessment
Upload your STEP, STL, or PDF engineering files for an accelerated 24-hour engineering assessment — including build feasibility analysis, lead time confirmation, surface finish options, and immediate pricing for single-unit NPI prototypes or multi-iteration design cycles.
Submit for Rapid AssessmentOne Metal. One Focus. Infinite Precision.
